Lithonia IBE-12LM-MVOLT-50K I-Beam® IBE LED High Bay Luminaire, 83W, 11,652 Lumens, 5000K CCT, 80CRI, 120-277V, Medium Distribution

Manufacturer: Lithonia Lighting | Catalog # IBE12LMMVOLT50K | Codale Part # 4239338
$216.43/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
LED economical linear bay light, 10,000LM, 120V, 4000K, 6FT cordset, NEMA 5-15P SJT, U-ground plug, 120V white cord, HC36 chain kit included in carton

Technical Information

Applications
Manufacturing,Warehouses
Average Rated Life
100,000 hr
Color Rendering Index
80
Color Temperature
5000 K
Correlated Color Temp
5,000 K
Dimmable?
Yes
Lamp Type
LED
Lens Color
White
Lens Material
Acrylic
Lumens
12, 000 Lumen
Material
Steel
Mounting Type
Pendant,Surface,Suspended
Power Source
Hardwired
Type
High Bay
Voltage
120 Volt
Wattage
83 Watt

Manufacturer Information

Brand
Lithonia Lighting

General Product Info

12-Digit UPC
191848491096
Color
White
Construction
New Construction,Remodel
Environment
Indoor
Environmental Conditions
Indoor
Finish
Gloss
Fixture Type
High Bay
Product UPC
19184849109
Shape
Rectangle
Weight
7.72 lb

Dimensions

Height
4.27 Inch
Length
21.93 Inch
Width
14.83 in

Certifications and Compliance

Country of Origin
Mexico,Mexico
Features
  • TECHNOLOGY: Easily replaces traditional 175 watt metal halide, 4-lamp T8 HBF, 2-lamp T5HO saving up to 48% energy
  • ENERGY SAVINGS: Integrated LEDs generate a nominal 12,000 lumens while efficiently using up to 83 watts to save money on utility bills
  • DIMMING: Thermally protected driver standard with 0-10V dimming
  • RATINGS: Meets highest standards - 6kV surge protection; UL , cUL certified to US and Canadian standards, listed for damp locations
  • VOLTAGE: Multi-volt 0-10V dimming driver
  • HOURS OF LIFE: 70% lumen maintenance at >100,000 hours.
  • INSTALLATION: Suitable for suspension by chain, cable, surface-mounting bracket, hook monopoint or single (pendant) monopoint
  • BATTERY: Field-installable LED emergency driver sold separately
  • WARRANTY: 5-year limited warranty
  • DIMENSIONS: Length 21.93 in. (55.7 cm) x Width 14.83 in. (37.7 cm) x Depth 4.27 in. (10.8 cm)
Applications
  • Manufacturing
  • Warehouses
Standards
  • cUL
  • UL
