Burndy RDM628 URD Mole, #4 Str - 250 kcmil Al or Cu 300 kcmil - 350 kcmil , 600 Volt Rating, 878 in L

Manufacturer: Hubbell-Burndy | Catalog # RDM628 | Codale Part # 4245475
$96.78/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
URD Mole, #4 Str. - 250 kcmil Al or Cu 300 kcmil - 350 kcmil , 600 Volt Rating, 8.78 in L.

Technical Information

Applications
For Aluminum And Copper And Direct Burial Or For Use In Enclosures
Conductor Size
1 AWG
Connection Type
Tap
Insulation Type
Rubber
Material
Aluminum
Type
RDM-28

Manufacturer Information

Brand
Hubbell Incorporated
Sub Brand
Burndy

General Product Info

12-Digit UPC
781810180051
Product UPC
78181018005
Weight
1.5920 lb

Dimensions

Height
2.94 Inch
Length
11-3/4 Inch
Overall Length
8.78 in
Width
2.94 in

Certifications and Compliance

Country of Origin
Mexico
CSA
No
Features
  • Type RDM-28 MOLE connectors are an economical, insulated, submersible service junction suitable for direct burial or for use in enclosures
  • Disconnectable Joints allow additions of new services without disturbing previous installations
  • Taping is eliminated, Heat Shrink or Force-Fit Rubber Sleeves insulated each joint, Rubber is used to insulate the MOLE body
  • Removable sealing covers are supplied on all outlets but two
  • REA Listed Tap Kits, including HYLUG, Hardware and Sleeve are ordered separately
