Burndy YAD28M10E38 Non-Insulated Brazed Barrel Copper Terminal; Accommodates: 4/0 AWG Str Code/Flex (95-120mm); Stud: 3/8"; Length: 220"

Manufacturer: Hubbell-Burndy | Catalog # YAD28M10E38 | Codale Part # 4258167
$37.99/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
Non-Insulated Brazed Barrel Copper Terminal, 3/8 ", 2.20 in L, Tin Plated, Ring Tongue.

Technical Information

Applications
The YAD uninsulated OEM lug terminal is constructed of electrolytic copper
Cable Size
4/0 AWG
Conductor Size
4/0 AWG
Connection Type
Ring Terminal
Material
Copper
Max Voltage
600 V
Plated?
Yes
Plating Type
Tin
Stud Size
0.375 in
Type
Ring Tongue
Voltage
35 kV

Manufacturer Information

Brand
Hubbell Incorporated
Sub Brand
Burndy

General Product Info

12-Digit UPC
781810549544
Product UPC
78181054954
Weight
0.1230 lb

Dimensions

Height
0.89 Inch
Hole Size
0.41 in
Length
2.21 Inch
Overall Length
56 mm
Width
0.85 in

Certifications and Compliance

Country of Origin
Taiwan
CSA
No
Features
  • Constructed of pure electrolytic copper for maximum conductivity, low resistance and ductility for excellent crimp forming properties
  • Long brazed seam barrel and deep V groove inner serrations provide optimum conductivity reliability and holding power aftercrimping
  • Electro-tin plating to provide durable, long-lasting corrosion resistance
  • Wire range is clearly marked on terminal for easy identification
  • Inspection hold for an easy visual check of wire insertion
  • Long neck terminal permits easy bending and stacking of several terminals on a common stud
