LEV 5WMNT-1C SDX MNI WM ENCL ACC 1

Manufacturer: Leviton | Catalog # 5WMNT-1C | Codale Part # 4268533

$179.21/ea
ea
Log in or register to view your price, purchase history, and more!
8 available

For Delivery

Not in local stock *
Check your local branch
To meet the demands of the Internet of Things (IoT), fog computing, and micro data center environments, the award-winning Leviton OPT-X SDX Mini Wall-Mount Fiber Optic Enclosure expands networking possibilities in a wide range of applications and environments. The space-saving footprint enables applications ranging from traditional telecommunications room patching in an enterprise setting to the implementation of small-scale edge data centers. It provides a compact, zero-RU patching field with a range of mounting options including wall-mount, surface-mount, DIN-rail, and even cubicle walls. The Mini Wall-Mount Enclosure also allows for more flexibility in traditional inter-connect or cross-connects between cable and active equipment while using minimum wall space. Its features and design allow for easy field termination of fiber connectors, splicing, or pre-terminated plug-and-play solutions

Technical Information

Applications
For Indoor Use
Gauge
16
Material
Steel
Mounting Type
Wall
Standard
CSA,NOM,UL
Type
Empty, No Lock, Mini

Manufacturer Information

Brand
Leviton
Sub Brand
Opt-X®

General Product Info

12-Digit UPC
078477824962
Color
Black
Finish
Powder Coated
Product UPC
07847782496
Used With
Fiber Enclosures, Entrance Facilities, Equipment Rooms, Telecommunications Rooms

Dimensions

Depth
6 Inch
Height
2.09 Inch
Width
6.53 in

Certifications and Compliance

Country of Origin
Mexico
Patents
  • US10433031
  • US10863251
Features
  • Enclosure accommodates up to 24 fibers (using LC), 12 fibers (using SC), and 6 ports (for copper)
  • Accepts SDX Precision-Molded Adapter Plates and SDX MTP Cassette for multiple solution capabilities
  • Removable cable entry/exit grommets allow for pre-terminated fiber trunk install, cable protection, and minimizes dust build up
  • Constructed of 16-gauge steel for enhanced durability
  • Optional key/lock kit secures the door for added physical security
  • Optional 0RU mounting bracket and magnet solutions available
  • Multiple application usage, including wall mount, 0RU in rack/cabinet, ladder rack, workstation, cubicle, and within an enclosure (using adhesive-based tapes or magnets)
