Sensor Switch CMR 9-1/4 Hp 120/277 VAC White 360 Degrees Ceiling Mount Passive Infrared Sensor

Manufacturer: Lithonia Lighting | Catalog # CMR9 | Codale Part # 4275396
$89.26/ea
ea
Log in or register to view your price, purchase history, and more!
118 available

For Delivery

Not in local stock *
Check your local branch
Primary Spec Sheet
Ceiling mount, line voltage, Standard range 360deg, small motion 360deg, SKU - 184CH2

Technical Information

Applications
Automotive & Parking,Bridges & Tunnels,Education,Government,Healthcare,Hospitality,House Of Worship,Manufacturing,Offices & Banks,Power & Gas,Residential,Retail,Roadways,Sports And Recreation,Transportation,Warehouses
Dimmable?
Yes
Lamp Life
87,600 hr
Lens Material
Plastic
Material
Plastic
Mounting Type
Flush,Surface
Power Source
Hardwired
Sensing Range
360 degrees
Standard
C-UL-US
Type
Sensor

Manufacturer Information

Brand
SensorSwitch

General Product Info

12-Digit UPC
745975808281
Color
White
Environment
Indoor
Environmental Conditions
Indoor
Finish
Matte
Product Type
Sensor
Product UPC
74597580828
Shape
Round
Weight
0.37 lb

Dimensions

Height
4-1/2 Inch
Length
4-1/2 Inch
Warranty Length
5 yr
Width
2.500 in

Certifications and Compliance

Country of Origin
Mexico
Features
  • DESIGN: Passive Infrared (PIR) occupancy detection
  • ENERGRY SAVINGS: Self-contained relay (no power pack needed)
  • DIMMING: Enjoy the flexibility and convenience of programming sensor settings with your smartphone using the SensorSwitch VLP Mobile App through camera flash programming
  • RATINGS: Energy Management Equipment, UL916 (E167435), RoHS compliant
  • MOUNTING: 12 ft radial coverage when mounted to standard 9 ft ceiling; 8-15 ft mounting heights provide 10-20 ft radial coverage
  • COVERAGE: 360 degree coverage
  • FEATURE: Best choice for small motion detection
  • BATTERY: 100-hour lamp burn-in timer mode
  • WARRANTY: 5-Year Limited Warranty
Application
  • Automotive & Parking
  • Education
  • Government
  • Healthcare
  • Hospitality
  • House of Worship
  • Manufacturing
  • Offices & Banks
  • Power & Gas
  • Residential
  • Retail
  • Roadways
  • Bridges & Tunnels
  • Sports and Recreation
  • Transportation
  • Warehouses
Mounting
  • Flush
  • Surface
Standard
  • C-UL-US
