Product image for Panduit PUR6C04BU-U Copper Cable, Cat 6, 23 AWG, U/UTP, CMR, Black
Image thumbnail 0
Image thumbnail 1
Image thumbnail 2
Email

Panduit PUR6C04BU-U Copper Cable, Cat 6, 23 AWG, U/UTP, CMR, Black

Manufacturer: Panduit | Catalog # PUR6C04BU-U | Codale Part # 4291389
$715.95/m (1000 ft)
ft
Order in multiples of 1000 (pack qty)
Log in or register to view your price, purchase history, and more!
2,000 available

For Delivery

Not in local stock *
Check your local branch
Buy American Compliant Buy American Compliant Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
The TX6™ Cat 6 U/UTP copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are twisted in pairs . All four pairs are surrounded by a PVC flame-retardant jacket. The blue, riser (CMR) cable is supplied 1,000 feet (305 meters) to an easy pay-out carton.

Technical Information

Applications
Indoor
Conductor Material
Copper
Conductor Size
23 AWG
Conductor Type
Solid
Insulation Material
Polyolefin
Max Operating Temperature
167 degrees F
Min Operating Temperature
-20 degrees C
Number of Conductors
4
Number of Pairs
4
Performance Level
Category 6
Standard
UL
Temperature Rating
-20 to 75 degrees C
Type
U/UTP

Packaging

Pkg Qty
1000

Manufacturer Information

Brand
Panduit Corp.
Sub Brand
PanNet

General Product Info

12-Digit UPC
074983220946
Color
Blue
Environment
Indoor
Jacket Material
Polyvinyl Chloride
Product UPC
07498322094
Weight
22 ft 1000 lb

Dimensions

Length
1000 Foot
Outer Diameter
0.21 in
Overall Length
1000 ft

Certifications and Compliance

Buy American Compliant
Y
Country of Origin
USA
Standards and Certifications
  • Standards Met: Exceeds ANSI/TIA-568.2-D Category 6 and ISO 11801 Class E with Channel Headroom Guarantee, meets IEEE 802.3af, IEEE 802.3at and IEEE 802.3bt for PoE applications, UL 1666 and CSA FT-4, RoHS Compliant.
