BUR YSR29FX28LTCKITC YSR29FX28LTCKI

Manufacturer: Hubbell-Burndy | Catalog # YSR29FX28LTCKITC | Codale Part # 4296383
$37.62/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
CU Splice Reducer, Barrel A 250 kcmil, 4/0 G,H,I,K,M,DLO, Barrel B 4/0 AWG, Standard Barrel, Internal Chamfer, Tin Plated, Connector is UL/CSA, 90.C Up to 35kV, Kit comes with Clear Heat Shrink, Yellow/Purple Color Code, 16/15 Die Index.

Technical Information

Color Coding
Purple,Yellow
Conductor Material
COPPER
Connection Type
Standard Barrel Kits
Material
Copper
Max Voltage
35000 V
Plated?
Yes
Plating Type
Tin - Electro Plated
Wire Size
-4/0 AWG

Manufacturer Information

Brand
Hubbell Incorporated
Sub Brand
Burndy

General Product Info

12-Digit UPC
781810415825
Finish
Tin Plated
Product UPC
781810415825

Dimensions

Length
3 Inch
Overall Length
76 mm

Certifications and Compliance

Country of Origin
USA
CSA
No
Features
  • Each splice kit includes one YSR-TC compression in-line splice reducer connector and heat shrink
  • Designed configurations allow for copper code-to-code wire connections, copper code-to-flex wire connections, and copper flex-to-flex wire connections
  • Barrel is designed with a taper to accommodate a main run wire that is reduced to a smaller tap wire
  • Electro-tin plated unless otherwise specified to reduce galvanic corrosion (bimetallic) and resist corrosive elements
  • Connectors clearly marked with color coding
