Product image for Burndy YKA282N HYLUG™, Copper Disconnectable Compression Terminal, With Fixed H/W, 2 Holes, 4/0 Str Cu, 1/2" Stud
Image thumbnail 0
Image thumbnail 1
Image thumbnail 2
Email

Burndy YKA282N HYLUG™, Copper Disconnectable Compression Terminal, With Fixed H/W, 2 Holes, 4/0 Str Cu, 1/2" Stud

Manufacturer: Hubbell-Burndy | Catalog # YKA282N | Codale Part # 4300797
$202.52/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
HYLUG™, Copper Disconnectable Compression Terminal, With Fixed H/W, 2 Holes, 4/0 Str Cu, 1/2" Stud

Technical Information

Conductor Size
4/0 AWG
Connection Type
Terminal
Material
Copper
Plated?
Yes
Plating Type
Tin

Manufacturer Information

Brand
Burndy

General Product Info

12-Digit UPC
781810014899
Product UPC
78181001489
Weight
10.1000 lb

Dimensions

Length
5.35 Inch
Overall Length
136 mm

Certifications and Compliance

Country of Origin
USA
CSA
No
Features
  • Tin-plated copper compression terminal with fixed hardware for making disconnectable tap or jumper connections
  • Used with slotted Type YTA-2N T-Tap or YSA-R-2N terminal
  • Supplied with tin-plated silicon bronze bolts and washer-face nuts
