Erico TDX200C120/208 Compact TDX Panel Protector, 200 kA, 120/208 V Un

Manufacturer: Cadweld | Catalog # TDX200C120/208 | Codale Part # 4304046
$2,081.64/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page
Transient discriminating technology for 120/208 3 phase systems.

Technical Information

Applications
Surge Protection; Power Connections
Enclosure Material
Metal
Enclosure Rating
IP 65
Standard
C-Tick,CE,UL
Type
Transient Discriminating Panel Protectors

Packaging

Standard Packaging Qty
1 pc

Manufacturer Information

Brand
nVent Erico
Sub Brand
ERICO

General Product Info

12-Digit UPC
782856670193
Product UPC
78285667019
Weight
2.00 kg

Dimensions

Depth
3.07 Inch
Height
11 Inch
Width
3.31 in

Certifications and Compliance

Certifications
CEC-TickUL
Features
  • Built-in features include TD Technology, thermal protection and short circuit current fusing
  • Compact NEMA®-4 enclosure design can be flush mounted or installed in a small space
  • LED status indication and voltage-free contacts provide remote status monitoring
  • 200 kA 8/20 ?s maximum surge rating provides protection suitable for main-distribution panels and an extended operational life
Certifications
  • UL ANSI/UL 1449
