Product image for Hubbell Wiring Devices CS8475 50 Amp 480 VAC 2-Pole 3-Wire Steel Casing Flanged Inlet
Image thumbnail 0
Image thumbnail 1
Image thumbnail 2
Email

Hubbell Wiring Devices CS8475 50 Amp 480 VAC 2-Pole 3-Wire Steel Casing Flanged Inlet

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # CS8475 | Codale Part # 4307774
$430.89/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
Locking Devices, Twist-Lock®, Industrial, Flanged Inlet, 50A 480V, 2-Pole 3-Wire Grounding, Non-NEMA, Screw Terminal, Black

Technical Information

Amperage
50 Amp
Applications
Extra Heavy Duty Industrial
Conductor Size
10-6 AWG
Contact Material
Brass
Current
50 Amp
Dielectric Strength
2500 VAC
Grounding
Grounding
Material
Steel
Mounting Type
Screw
Number of Phases
1 Phase
Number of Poles
2 Pole
Number of Wires
2 Wire
Operating Temperature
-40 degrees C
Size
Standard Sized
Standard
CSA C22.2 No.42,UL 498
Tc Connection
Pressure Screw Terminals
Temperature Rating
-40 to 75 degrees C
Type
Standard Single
Voltage
480 Volt
Wattage
24000 Watt
Wire Count
3
Wire Size
10-6 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Twist-Lock®

General Product Info

12-Digit UPC
783585876801
Color
Metallic
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
Product UPC
78358587680
Weight
0.95 lb

Dimensions

Height
2.17 Inch
Length
3-1/2 Inch
Width
2.62 in

Certifications and Compliance

Country of Origin
Puerto Rico
Features
  • Metallic flanged casing provides maximum strength and protection
  • Thermoset interior provides superior heat resistance
  • Standard Product
