Burndy HSC112FRFT Heat Shrinkable Thin Wall Tube, 600 V, Shrink Ratio: 2 : 1

Manufacturer: Hubbell-Burndy | Catalog # HSC112FRFT | Codale Part # 4317102
$12.63/ea
ft
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
Heat Shrinkable Thin Wall Tube, 600 V, Shrink Ratio: 2 : 1.

Technical Information

Applications
For Terminations And Splices
Shrink Ratio
2 : 1
Type
HSC-FR, Thin Wall, Flexible, Fire Retardant
Voltage
600 Volt

Manufacturer Information

Brand
Burndy
Sub Brand
VISISHRINK

General Product Info

12-Digit UPC
781810033739
Color
Colorless
Product UPC
78181003373
Weight
0.0920 lb

Dimensions

Height
600 Inch
Inside Diameter
0.75 IN
Length
600 Inch
Thickness
04 IN Wall
Width
1.58 in

Certifications and Compliance

Country of Origin
USA
CSA
Yes
Features
  • Type HSC-FR Is A Flexible Polyvinyl Chloride Clear Heat-Shrink Tubing, Excellent Flame Retardant Properties And A 2:1 Shrink Ratio, The VISI-SHRINK Tubing Enables Inspectors To Read Die Index Embossments On Installed Connectors Easily, UL Recognized, 105 DEG C, 600V, The Operating Temperature From -20 To 105 DEG C With A Shrink Temperature Of 135 DEG C, UL 224, VW-1 Rated, Self-Extinguishing Flame Retardant Properties, Clear Tubing, Allows Inspection Of Die Index Embossed And Shiner After Installation Is Complete, Should Any Corrosion Occur It Will Be Visible During Inspection, Low Shrink Temperature, Only Requires Common Hot Air Guns To Apply, Meets MIL-M-23053/Z-206C, Inner Diameter Expanded: 1.5 IN, Inner Diameter After Recovery: 0.75 IN, Conductor Range: 350 - 750 KCMIL (Code), 250 - 500 KCMIL (Flex), Material: Polyvinyl Chloride
