HWDK HBL54CM66C MARINE PLUG, 20A 25

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBL54CM66C | Codale Part # 4325393
$125.05/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
Straight Blade Devices, Male Plug, Corrosion Resistant, Industrial/Commercial Grade, Straight, 2-Pole 3- Wire Grounding, 20A 250V, 6-20P, Yellow, Single Pack.

Technical Information

Amperage
20 Amp
Applications
Marine Wiring Devices
Conductor Size
18-10 AWG
Cord Type
Portable
Current
20 Amp
Horsepower
2 hp
Material
Thermoplastic
NEMA
6-20P
Number of Poles
2 Pole
Number of Wires
3 Wire
Operating Temperature
-40 degrees C
Size
Standard Sized
Standard
CSA,E2186,UL
Style
Corrosion Resistant
Tc Connection
Spade, 2 Terminals
Type
Standard Sized
Voltage
250 Volt
Wattage
5000 Watt
Wire Count
3
Wire Size
18-10 AWG

Manufacturer Information

Brand
Hubbell Incorporated
Sub Brand
Straight Blade and Twist-Lock

General Product Info

12-Digit UPC
783585013381
Color
Black on Yellow
Environmental Conditions
Indoor Only
Product Series
Insulgrip
Product UPC
78358501338
Weight
0.15 lb

Dimensions

Height
1.53 Inch
Length
2.78 Inch
Width
1.53 in

Certifications and Compliance

Country of Origin
USA
Features
  • Ribbed nylon housing is impact and chemical resistant
  • VARI-SIZE adjustable cord clamp
  • Fast lead assembly screws
  • Beveled housing prevents snagging
