LITH LDN6 ALO2 SWW1 MVOLT UGZ HSG L

Manufacturer: Lithonia Lighting | Catalog # LDN6-ALO2-SWW1-MVOLT-UGZ- HSG | Codale Part # 4330191
$180.47/ea
ea
Log in or register to view your price, purchase history, and more!
66 available

For Delivery

Not in local stock *
Check your local branch
Primary Spec Sheet

Technical Information

Aperture Size
6 in
Applications
Bridges & Tunnels,Education,Government,Healthcare,Hospitality,Offices & Banks,Retail,Roadways
Color Rendering Index
80
Color Temperature
Variable K
Correlated Color Temp
0 K
Dimmable?
Yes
Lamp Life
50,000 hr
Lamp Type
LED
Lens Color
Clear
Lens Material
Polycarbonate
Lumens
1,000 Lumen
Material
Steel
Mounting Type
Recessed
Number of Lamps
1
Power Source
Hardwired
Type
Housing
Voltage
120 Volt
Wattage
25.6 Watt

Manufacturer Information

Brand
Lithonia Lighting

General Product Info

12-Digit UPC
194994869917
Construction
New Construction
Environment
Indoor
Environmental Conditions
Indoor
Product UPC
19499486991
Shape
Round
Weight
35.041 lb

Dimensions

Height
7-1/2 Inch
Length
11-1/2 Inch
Width
11.25 in

Certifications and Compliance

Country of Origin
Mexico,Mexico
Features
  • TECHNOLOGY: LDN Switchable offers switchable CCTs (3000K-3500K-4000K-5000K) and switchable lumens (ranging from 1000-2000LM) as well as a combo driver capable of handling phase dimming (120V) and 0-10V (MVOLT).
  • ENERGY SAVINGS: Long-life LEDs, coupled with a high-efficiency driver, provide superior illumination for extended service life, and up to 114 LPW
  • DIMMING: MVOLT 120-277V, 0-10V and phase dimming in an all-in one driver for 10% dimming
  • RATINGS: Energy Star, Wet Location, Damp Location, Title 20
  • VOLTAGE: MVOLT 120-277V, 0-10V and phase dimming (120V)
  • HOURS OF LIFE: L80 at 60,000 hours
  • INSTALLATION: Traditional mounting frame allows for a quick installation for new construction applications
  • BATTERY: Emergency battery pack not included, available for purchase separately. Refer to spec sheet for field installed battery pack options.
  • WARRANTY: 5-year limited warranty
  • DIMENSIONS: (l x w x h) 14 7/8 in. x 12 9/16 in. x 6 1/8 in.
Applications
  • Education
  • Government
  • Healthcare
  • Hospitality
  • Offices & Banks
  • Retail
  • Roadways
  • Bridges & Tunnels
Standards
  • cULENERGY STAR
  • Low UGR
