Erico EDT235030R EDT2 Enhanced DIN Rail Surge Protection Class II, 3+0 Mode, 277 V Un

Manufacturer: Cadweld | Catalog # EDT235030R | Codale Part # 4340730
$400.29/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page
EDT2 Enhanced DIN Rail Surge Protection Class II, 3+0 Mode, 277 V Un

Technical Information

Applications
Power Connections
Type
EDT2 Series Enhanced Transient Discriminating Surge Protective Devices

Manufacturer Information

Brand
nVent Erico

General Product Info

12-Digit UPC
782856939078
Product UPC
78285693907
Weight
0.41 kg
Certifications
  • CE, ERICO EDT2 DIN EN 61643-11 (VDE 0675-6-11):2013-04; EN 61643-11:2012; IEC 61643-11:2011
  • VDE DIN EN 61643-11 (VDE 0675-6-11):2019-03; EN 61643-11:2012+A11:2018 IEC 61643-11:2011
  • UR ANSI/UL 1449
  • cUR CSA C22.2 No. 269.4
Features
  • Includes nVent ERICO TD Technology to ensure reliability throughout adverse voltage conditions
  • Enhanced temporary over voltage (TOV) withstand capability
  • External back-up fuse is not required up to 315 A (IEC only)
  • Compact, yet high surge rated pluggable design, using minimum DIN rail width
  • Retaining clip ensures enhanced vibration and shock resistance performance
  • Red/Green status indication and change-over contacts standard for remote monitoring
