Product image for Hoffman A72XM7818FTCLP4 Free-Stand Disconnect with Quick-Release Hinge, Type 4, 72.12" x 78.5" x 18.12", Gray, Steel
Image thumbnail 0
Image thumbnail 1
Email

Hoffman A72XM7818FTCLP4 Free-Stand Disconnect with Quick-Release Hinge, Type 4, 72.12" x 78.5" x 18.12", Gray, Steel

Manufacturer: nVent Hoffman | Catalog # A72XM7818FTCLP4 | Codale Part # 4364764
$20,543.85/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
Simple, heavy-duty and cost-effective with easy door removal and re-installation, this disconnect enclosure can be ordered with one to three doors to fit a range of indoor and outdoor applications

Technical Information

Applications
Schools, Hospitals, Office Buildings, Airports, Casinos, Stadiums, Petrochemical Plants, Automotive Plants Paper Plants, Food Processing, Power Plants Refineries, Manufacturing, Mining
Color Coding
ANSI 61
IP Rating
66
Material
Steel
Size
72.12 x 78.50 x 18.12 in
Type
Type 4 Mild Steel Freestanding Enclosure

Manufacturer Information

Brand
nVent Hoffman
Sub Brand
Hoffman

General Product Info

12-Digit UPC
783510278137
Color
Gray
Finish
Powder Coated
Product UPC
78351027813
Weight
741 lb

Dimensions

Depth
18.12 Inch
Height
72.12 Inch
Length
36 Inch
Thickness
3.04 mm
Width
78.5 in
DISK UNSPSC
39121324
Features
  • Quick-release continuous hinge
  • Seams continuously welded and ground smooth
  • Body stiffeners in larger enclosures for extra rigidity
  • Body flange trough excludes liquids and contaminants
  • Heavy-duty lifting eyes anchor into reinforced top
  • Removable centerposts permit easy panel installation
  • Heavy-duty 3-point latching mechanism operated by padlocking handle on all doors
  • Ends of latch rods have rollers for easier door closing
  • Panel supports
  • Data pocket is high-impact thermoplastic
  • Oil-resistant gasket
  • Master door is far right-hand door on all enclosures
  • Defeater on primary door requires a screwdriver to open
  • Mechanical interlock activated by master door prevents slave doors from being opened first; doors can be closed in any order
  • Universal cutout on right flange provides mounting for most disconnect operators by using operator adapters
  • Models do not include panels. Painted or conductive panels sold separately.
  • Includes door hardware
