RAB A17XFU150 Area A17 3WAY CCT 70W

Manufacturer: RAB Lighting | Catalog # A17XFU150 | Codale Part # 4366186

$485.38/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.

The XFU models of the A17 have three selectable features: 3 selectable wattages, 3 selectable color temperatures, and a twistlock photocell, giving you 18 SKUs in one area light. Not only does the A17 offer an ultra-high efficacy of up to 153 lm/W, but it delivers high efficacy throughout its entire portfolio. This ultra-economy area light is IES Type III and field adjustable light output of 70W/100W/150W with 0-10V dimming.



Rab Lighting A17XFU150 Features:

  • Color Adjustable: 5000K/4000K/3000K
  • 3-pin twistlock and shorting cap included
  • With universal mounting arm
  • Integrated NEMA 7-pin receptacle enables easy upgrade to smart controls
  • 0-10V Dimming, standard
  • 100,000-hour LED lifespan
  • 5-Year, limited warranty

Technical Information

Ambient Temperature
104 degrees F
Color Accuracy
71 CRI
Efficacy
134 LPW
Input Wattage
69.8-151.22
Lens Material
Polycarbonate
Lumens
11,168 Lumen
Minimum Starting Temp
-40 degrees C
Type
Constant Current
Wattage
150

Manufacturer Information

Brand
Must Be Procured By Salesperson

General Product Info

12-Digit UPC
192552036276
Finish
Bronze
Product UPC
19255200387
Weight
13.2 lb
Features
  • Color Adjustable: 5000K/4000K/3000K
  • Power Adjustable: 70W/100W/150W
  • 3-pin twistlock and shorting cap included
  • Integrated NEMA 7-pin receptacle enables easy upgrade to smart controls
  • 0-10V Dimming, standard
  • 100,000-hour LED lifespan
  • 5-Year, Limited Warranty
  • 5 Yr Limited Warranty
  • Buy American Act Compliance
