Hubbell HBL2366 Locking Flanged-Receptacle, 20A 125/250V, L10-20R, WH

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBL2366 | Codale Part # 4384594
$174.44/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page
Locking Devices, Twist-Lock®, Industrial, Insulgrip® Flanged Receptacle, 20A 125/250V, 3-Pole 3-Wire Non-Grounding, NEMA L10-20R, Screw Terminal, Nylon casing, Back wired, White.

Technical Information

Amperage
20 Amp
Applications
Insulgrip
Conductor Size
16-8 AWG
Contact Material
Brass
Current
20 Amp
Dielectric Strength
Withstands 2,000V minimum
Flamability Class
HB Or Better Per UL94/CSA 22.2 No.0.17
Material
Nylon
NEMA
L10-20R
Number of Phases
1 Phase
Number of Poles
3-3 Pole
Number of Wires
3,3
Operating Temperature
-40 degrees C
Screw Material
#10-32 Brass
Size
Standard Sized Product
Standard
CSA C22.2 No.42,Fed.Spec. W-C-596,UL 498
Tc Connection
Screw Terminal
Type
Flanged Receptacle
Voltage
125/250 Volt
Wattage
5000 Watt
Wire Count
3
Wire Size
16-8 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Twist-Lock Devices

General Product Info

12-Digit UPC
783585128979
Color
White,White
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
Product UPC
78358512897
Weight
0.2000 lb

Dimensions

Height
2.98 Inch
Length
2.98 Inch
Width
2.980 in

Certifications and Compliance

Country of Origin
USA
Features
  • Backwired terminations for ease of installation
  • #10-32 Multiple drive terminal screws (Slotted, Phillips, Robertson)
  • Mounting screws included
  • Standard
