Panduit SPF2-4-C Ground Connector-Service Post, Female Thread, two-Conductors

Manufacturer: Panduit | Catalog # SPF2-4-C | Codale Part # 4427272

$6,779.78/c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
The SPF2-4-C Service Post Grounding Connector is designed for grounding two copper code conductors to steel structures, busbars, transformers. The true hex design for body and nut hex provides correct fit with socket, box, or open-end wrenches, resulting in proper torquing of electrical connection. The pressure bar provides a secure connection on a full range of conductor combinations used with each connector providing a premium wire pull-out strength. UL Listed for grounding and bonding.

Technical Information

Applications
Utility/Ground Grid
Material
Bronze
Tc Connection
Connecting Conductors of Various Sizes to External Threaded Studs
Type
Grounding Connector

Packaging

Pkg Qty
100

Manufacturer Information

Brand
Panduit Corp.
Sub Brand
StructuredGround™

General Product Info

12-Digit UPC
074983716968
Product UPC
07498371696
Weight
12.1000 lb

Dimensions

Length
1.56 Inch
Overall Length
1.56 in

Certifications and Compliance

Buy American Compliant
Y
Country of Origin
USA
Standards and Certifications
  • Standards Met: cULus Listed - 467, DB Rated
