Lithonia CPHB-ALO13-MVOLT-SWW9-80CRI-DWH Compact Pro™ 14" Contractor LED High Bay Fixture, 120-277V, 12000/15000/18000 Lumens, 4000K/5000K, White

Manufacturer: Lithonia Lighting | Catalog # CPHBALO13MVOLTSWW980CRIDWH | Codale Part # 4433011
$202.92/ea
ea
Log in or register to view your price, purchase history, and more!
75 available

For Delivery

Not in local stock *
Check your local branch
Primary Spec Sheet
Compact Pro High Bay, LED, Switchable Lumens- 12000LM, 15000LM and 18000LM, 120V-277V, Switchable CCT- 4000K and 5000K, 80 color rendering index, White

Technical Information

Applications
Common Areas,Education,Government,Manufacturing,Offices & Banks,Retail,Retrofit,Warehouses
Average Rated Life
100,000 hr
Color Rendering Index
80
Color Temperature
4000 K
Lamp Life
100,000 hr
Lamp Type
LED
Lens Color
Clear
Lens Material
Acrylic
Lumens
Switchable Lumen
Material
Aluminum
Mounting Type
Pendant,Surface,Suspended
Number of Lamps
2
Standard
CSADLC Premium
Style
Traditional
Type
High Bay
Voltage
120 Volt
Wattage
138 Watt

Manufacturer Information

Brand
Lithonia Lighting

General Product Info

12-Digit UPC
196183428561
Color
White
Construction
New Construction,Remodel
Environment
Indoor
Environmental Conditions
Indoor
Finish
Gloss
Product Type
High Bay
Product UPC
19618342856
Shape
Rectangle
Weight
6.5 L

Dimensions

Height
2.4 Inch
Length
14.4 Inch
Warranty Length
5 yr
Width
11.5 in

Certifications and Compliance

Country of Origin
Malaysia
Features
  • The Compact Pro High Bay by Lithonia Lighting (CPHB) is the budget-oriented high bay designed for contractors from the ground up. Its the most compact high bay on the market, making it easier and quicker to install. Built with quality to last and performance to get the job done.
  • TECHNOLOGY: Adjustable Lumen Output (ALO) and Switchable White (SWW) features allow for this panel to offer 12 configurations in 2 SKUs
  • ENERGY SAVINGS: Long-life LEDs, coupled with a high-efficiency driver, provide superior illumination for extended service life
  • DIMMING: Thermally protected driver standard with 0-10V dimming
  • RATINGS: CSA listed, Damp location listed, DLC 5.1 qualified, designed for ambient temperature ranging -40°C to 55°C
  • VOLTAGE: Standard MVOLT for 120-277 volts
  • HOURS OF LIFE: 70% lumen maintenance at > 100,000 hours
  • INSTALLATION: Includes V-hanger hardware brackets and 2-36 chain lengths; also suitable for mounting by chain, cable, surface-mount bracket, or hook monopoint
  • BATTERY: Emergency battery pack available, sold separately
  • WARRANTY: 5-year limited warranty
