Product image for Lithonia CPHB-ALO16-MVOLT-SWW9-80CRI-DWH Compact Pro™ 22" LED High Bay, 24000/27000/30000 Lumens, 4000/5000K, 120-277V, 80 CRI
Image thumbnail 0
Image thumbnail 1
Image thumbnail 2
Image thumbnail 3
Image thumbnail 4
Image thumbnail 5
Email

Lithonia CPHB-ALO16-MVOLT-SWW9-80CRI-DWH Compact Pro™ 22" LED High Bay, 24000/27000/30000 Lumens, 4000/5000K, 120-277V, 80 CRI

Manufacturer: Lithonia Lighting | Catalog # CPHB ALO16 MVOLT SWW9 80CRI DWH | Codale Part # 4433013
$238.15/ea
ea
Log in or register to view your price, purchase history, and more!
95 available

For Delivery

Not in local stock *
Check your local branch
Primary Spec Sheet
The Compact Pro High Bay by Lithonia Lighting (CPHB) is the budget-oriented high bay designed for contractors from the ground up. It.s the most compact high bay on the market, making it easier and quicker to install. Built with quality to last and performance to get the job done.

Technical Information

Applications
Six common tap sizes (6-32, 8-32, 10-32, 10-24, 12-24, 1/4-20)
Average Rated Life
100,000 hr
Color Rendering Index
80
Color Temperature
4000 K
Correlated Color Temp
4000 K
Lamp Life
100,000 hr
Lamp Type
LED
Lens Color
Clear
Lens Material
Acrylic
Lumens
Switchable Lumen
Material
Aluminum
Mounting Type
Pendant,Surface,Suspended
Number of Lamps
2
Standard
CSA
Style
Traditional
Type
High Bay
Voltage
120 Volt

Manufacturer Information

Brand
Lithonia Lighting

General Product Info

12-Digit UPC
196183428578
Color
White
Construction
New Construction,Remodel
Environmental Conditions
Indoor
Finish
Gloss
Product Type
High Bay
Product UPC
19618342857
Shape
Rectangle
Weight
8.1 L

Dimensions

Height
2.4 Inch
Length
22.8 Inch
Warranty Length
5 yr
Width
11.5 in

Certifications and Compliance

Country of Origin
Malaysia
Features
  • The Compact Pro High Bay by Lithonia Lighting (CPHB) is the budget-oriented high bay designed for contractors from the ground up. Its the most compact high bay on the market, making it easier and quicker to install. Built with quality to last and performance to get the job done.
  • TECHNOLOGY: Adjustable Lumen Output (ALO) and Switchable White (SWW) features allow for this panel to offer 12 configurations in 2 SKUs
  • ENERGY SAVINGS: Long-life LEDs, coupled with a high-efficiency driver, provide superior illumination for extended service life
  • DIMMING: Thermally protected driver standard with 0-10V dimming
  • RATINGS: CSA listed, Damp location listed, DLC 5.1 qualified, designed for ambient temperature ranging -40°C to 55°C
  • VOLTAGE: Standard MVOLT for 120-277 volts
  • HOURS OF LIFE: 70% lumen maintenance at > 100,000 hours
  • INSTALLATION: Includes V-hanger hardware brackets and 2-36 chain lengths; also suitable for mounting by chain, cable, surface-mount bracket, or hook monopoint
  • BATTERY: Emergency battery pack available, sold separately
  • WARRANTY: 5-year limited warranty
