Hoffman EF300-24R5 Filter Fan, 24V DC, Cut Out 223mm x 223mm

Manufacturer: nVent Hoffman | Catalog # EF300-24R5 | Codale Part # 4433149
$688.03/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
Filter fan for forced ventilation. This High Flow Filter Fan, EF, EF300-24R5 item measures 252x252x103mm has a material of Thermoplastic color Light Gray, finish Smooth.

Technical Information

Color Coding
RAL 7035
Material
Thermoplastic

Manufacturer Information

Brand
nVent Hoffman

General Product Info

12-Digit UPC
783510474782
Color
Gray
Finish
Smooth
Product UPC
78351047478
Weight
3.70 lb

Dimensions

Depth
4.04 Inch
Height
10.55 Inch
Length
10.3 Inch
Width
10.30 in
Features
  • Description: Filter fan for forced ventilation. nVent HOFFMAN filter fans save time on installation as they are installed with a click-in system without screws. The hinged front cover can be easily opened for quick and easy filter replacement. The airflow direction and the connection position can easily be changed.
  • Material: Front cover manufactured from injection-moulded thermoplastic, self-extinguishing, UL94V0.
  • Temperature range: -40 °C to +55 °C.
  • Protection: IP 54, TYPE 12.
  • Finish: RAL 7035.
  • Pack quantity: One fan with filter.
  • The filter fan is reliable due to its high quality motor, as well as being easy to install
  • Component failure and unnecessary downtime is avoided as water and dust are prevented from entering the enclosure and the reliable motor ensures that there is constant ventilation
  • The click-in feature reduces the customer's labour cost due to the ease of installation
  • The filter fan should be installed together with at least one exhaust filter, EFA
  • Bearing Type: Sleeve
