Raco 232MS 4" Square Box, Welded with STAB-IT Connector, 2-1/8" Deep, 600V, Raised Ground, 8" #12 Copper Pigtail, UBS, M Bracket

Manufacturer: Raco | Catalog # 232MS | Codale Part # 4453503
$2,761.51/c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet MDM Safety Data Sheet
4 in. Square Box, Welded with STAB-IT® Connector, 2-1/8 in. Deep, 600V, Raised Ground, 8 in. #12 Copper Pigtail, UBS, M Bracket

Technical Information

Applications
Commercial
Material
Steel
Number of Gangs
2 Gang

Manufacturer Information

Brand
RACO

General Product Info

12-Digit UPC
050169500736
Color
Gray
Product UPC
05016950073
Shape
Square
Weight
1.131 lb

Dimensions

Depth
2-1/8 Inch
Height
4.14 Inch
Length
2.64 Inch
Width
5.86 in

Certifications and Compliance

Country of Origin
China
Features
  • Welded steel construction with \"UBC\" support with preset bend points to work with wall thickness 2-1/2 to 6 in. and \"M\" brackets on both sides of the box
  • 4 in. square x 2-1/8 in. deep
  • Designed for quick installation of flex, MC, MCI, MCI-A, AC, and HCF Cable
  • TKO® Knockouts allow design and installation flexibility
  • Supplied with seven 1/2 in. and four 1/2-3/4 in. TKO® knockouts
  • Combination Phillips/slotted screw heads
  • 30.3 cu. in. capacity
  • Includes 8 in. #12 solid copper ground pigtail
  • Acceptable for use in 2-hour fire rated walls
