Leviton CS6369 50 Amp 125/250 VAC 3-Pole 4 Wire Black and White Industrial Grade Black Locking Flush Mount Receptacle

Manufacturer: Leviton | Catalog # CS6369 | Codale Part # 4454502
$176.58/ea
ea
Log in or register to view your price, purchase history, and more!
17 available

For Delivery

Not in local stock *
Check your local branch
Primary Spec Sheet MDM Safety Data Sheet
50Amp, 125/250V AC, Non-NEMA, 3P, 4W, Black & White Locking Flush Mount Receptacle, Industrial Grade, Grounding, California-Style(CS) . BLACK

Technical Information

Amperage
50 Amp
Applications
Commercial
Body Material
Impact Modified Nylon
Conductor Size
10-6 AWG
Device Type
Locking Receptacle
Dielectric Strength
2000 (Min.)
Flamability Class
Rated HB Or Better UL94
Grounding
Grounding
Material
Nylon
Mounting Type
Box
Number of Poles
3 Pole
Number of Wires
4 Wire
Operating Temperature
-40 degrees C
Size
3.69 H x 2.13 W x 1.14 D IN
Standard
CSA C22.2 No. 42 (File 152105),NOM Certified (057),RoHS Compliant,UL Listed 498 (File E13399)
Temperature Rating
-40 To 75 degrees C
Temperature Rise
150 %
Type
Flush Mount Locking Receptacle
Voltage
125 Volt
Wire Count
4
Wire Size
10-6 AWG

Manufacturer Information

Brand
Leviton
Sub Brand
50AMP

General Product Info

12-Digit UPC
078477326282
Color
Black
Environment
Dry
Environmental Conditions
Flammability (Rated V-0 per UL94)
Product UPC
07847732628
Weight
0.7400 lb

Dimensions

Warranty Length
Lifetime Limited

Certifications and Compliance

Country of Origin
Mexico
Features
  • One piece contacts reduce friction and overheating
  • Unique cord clamp accepts wide range of cord sizes
  • Rugged nylon construction resists impact, sunlight, chemicals, and rough use
  • 10-year limited warranty
NEMA
  • Non-NEMA
