BELDEN 5302FE 008U1000 18/4C (X) OAFS PVC GRY CMR

Manufacturer: Belden | Catalog # 5302FE | Codale Part # 4455463
$698.14/m (1000 ft)
ft
Order in multiples of 1000 (pack qty)
Log in or register to view your price, purchase history, and more!
9,000 available

For Delivery

Not in local stock *
Check your local branch
Primary Spec Sheet
Security & Sound Cable, Riser-CMR, 4-18 AWG stranded bare copper conductors with polypropylene insulation, Beldfoil® shield and PVC jacket with ripcord

Technical Information

Amperage
4 Amp per Conduc-r at 25 C
Applications
For Security System, Intercom/PA, Audio/Speaker, Power-Limited Controls
Bend Radius
1.8 in
Conductor Material
Bare Copper
Conductor Size
18 AWG
Insulation Material
Polypropylene
Insulation Thickness
0.009 in
Material
PVC
Number of Conductors
4
Resistance
6.5 ?/1000 ft
Shield Type
Tape
Shielding Type
Overall Foil Tape
Stranding
7x26
Temperature Rating
-20 to 75 degrees C
Type
Security and Sound, Shielded
Voltage
300 Volt

Manufacturer Information

Brand
Belden

General Product Info

12-Digit UPC
612825159537
Environment
Indoor,Riser
Jacket Color
Gray
Jacket Material
PVC
Jacket Thickness
0.017 in
Product UPC
5302FE008U1000
Weight
31 lb/1000 ft

Dimensions

Outside Diameter
0.188 in
Suitable Applications
  • Security System, Intercom/PA, Audio/Speaker, Power-Limited Controls, Noisy Environment
