PAN H200X084H1T-2 H200X084H1T-2 Hea

Manufacturer: PANDUIT | Catalog # H200X084H1T-2 | Codale Part # 4461121

$1,302.64/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
The thermal transfer military grade printable heat-shrink label in white is two-sided with a 1/2" (12.7 mm) diameter and made of 3:1 flattened polyolefin. It is 2.0" wide and 0.84" high (50.8 x 21.3 mm). The heat-shrink sleeve is designed to provide a clear, reliable, and durable way to identify wires and cables. The sleeve has 1 label per row and 500 labels per roll. Heat-shrink labels are mounted on a plastic carrier and offer crisp, clear legends with superior readability for quick and easy label production in all label formats, including thermal transfer and dot matrix printable.

Technical Information

Material
Polyolefin
Max Operating Temperature
135 degrees C
Min Operating Temperature
-55 degrees C
Size
2.00 x 0.84 IN
Type
Heat Shrink Label

Packaging

Pkg Qty
1

Manufacturer Information

Brand
Panduit Corp.
Sub Brand
Pan-Code

General Product Info

12-Digit UPC
074983088669
Color
White
Product UPC
07498308866
UNSPSC
55121612
Weight
2.3500 lb

Dimensions

Diameter
12.7 mm
Height
0.84 Inch
Overall Length
0 in
Width
2 in

Certifications and Compliance

Buy American Compliant
Y
Country of Origin
USA
Standards and Certifications
  • Standards Met: (1) Material is RoHS compliant (European Union directive 2002/95/EC).(2) AMS-DTL-23053/5C (Class 1 and Class 3) and UL standard 224 with a VW-1 rating. (3) When printed using RMH4BL,RMEH4BL, RHH4BL-S, RMR4BL, RMER4BL, RMR4WH, RHR4BL-S, or RMR2BL thermal transfer ribbons it will also meet SAE-AS5942, MILSTD-883F Method 2015.13, and MIL-STD-202G Method 215K.(4) RoHS Compliant
