LEV E5325-W DECORA EDGE RECPT 15A12

Manufacturer: Leviton | Catalog # E5325-W | Codale Part # 4462529
$5.72/ea
ea
Log in or register to view your price, purchase history, and more!
300 available

For Delivery

Not in local stock *
Check your local branch
Primary Spec Sheet
15 Amp, 125 Volt, NEMA: 5-15R, 2 Pole, 3-Wire, Straight Blade, Decora Duplex Tamper-Resistant Outlet, Self-grounding, UL/CSA, NEC compliant - White

Technical Information

Amperage
15 Amp
Connection Type
Side Lever
Device Type
Decora Duplex Receptacle
Grounding
Self-Grounding
Number of Poles
2 Pole
Number of Wires
3 Wire
Termination Type
Side Lever
Type
Duplex
Voltage
125 Volt

Manufacturer Information

Brand
Leviton
Sub Brand
Decora®

General Product Info

12-Digit UPC
078477332559
Color
White
Product UPC
07847733255

Dimensions

Warranty Length
2 yr

Certifications and Compliance

Country of Origin
China
Features
  • Provides the traditional appearance and superior performance of Decora® devices in a new, faster, easier-to-install, and safer design
  • Unique lever terminals for fast, efficient wiring
  • Color-coded lever terminals reduces risk of miswiring
  • Lever doors have snap feature to assure connection has been made; audible click confirms lever door is closed
  • Only Residential device on the market with a quick termination ground wire
  • No exposed metal parts for enhanced safety; eliminates need for electrical tape
  • Straps unique tongue and groove alignment offers quicker trim out on multi-gang installations
  • Lever connectors work with 14 gauge and 12 gauge stranded and solid copper wire
  • Wire openings prevent wire insulation from being inserted into the terminals
  • One standard strip gauge for all devices
  • Devices coordinate seamlessly with other Decora devices
  • Longer and wider strap is compatible with Midway wallplates, and with Standard sized wallplates when breakaway tab is removed
  • Can be used with Decora wallplates and Decora Plus™ screwless wallplates
  • Outlet allows for split circuit applications
  • Outlet is Tamper-Resistant to help prevent access by most non-rated/foreign objects
  • FASTER Unique lever terminals for fast, efficient wiring. As Easy as PUSH. CLICK. DONE.
  • EASIER Large strap makes installations easier as well as the ability to use 14 gauge and 12 gauge stranded and solid copper wire
  • SAFER No exposed metal parts for enhanced safety
  • CONVENIENT Color-coded lever terminals to help prevent miswiring
  • COMPATIBLE Coordinates seamlessly with other Decora devices and can be used with any sized Decora wallplate
Patents
  • CA2621644
  • CA2624409
  • US11791573
  • US7355117
  • US7820909
  • US8242362
