LEV G5362-2TW 20A 2/PLUG MARKED CON

Manufacturer: Leviton | Catalog # G5362-2TW | Codale Part # 4513414
$65.52/ea
ea
Log in or register to view your price, purchase history, and more!
166 available

For Delivery

Not in local stock *
Check your local branch
Primary Spec Sheet MDM Safety Data Sheet
2 Plug Marked Controlled SmartlockPro GFCI Decora Duplex Receptacle Outlet, Extra Heavy-Duty Industrial Grade, Tamper-Resistant, Power Indication, 20 Amp, 125 Volt, Back or Side Wire, NEMA 5-20R, 2-Pole, 3-Wire, Self-Grounding . White

Technical Information

Amperage
20 Amp
Body Material
Polycarbonate
Device Type
Duplex Receptacle Outlet
Face Material
PBT
Flamability Class
Rated V-0 Per UL 94
Grade
Extra Heavy-Duty Industrial Specification
Grounding
Self-Grounding
Horsepower
1 hp
NEMA
5-20R
Number of Poles
2.0
Number of Wires
3 Wire
Operating Temperature
-35 degrees C
Short Circuit Current
10 kA
Standard
ANSI C-73,CSA C22.2 No. 42 & 144,FedSpec W-C-596,UL 498,UL 943
Termination Type
Back Wire,Side Wire
Wire Count
3

Manufacturer Information

Brand
Leviton
Sub Brand
TAMPER RESISTANT C I GFCI

General Product Info

12-Digit UPC
078477433645
Color
White
Product UPC
07847743364

Dimensions

Warranty Length
2 yr

Certifications and Compliance

Certifications
CSA,NOM-ANCE,UL
Country of Origin
China
Patents
  • CA2865659
Features
  • Peace of mind, all the time. The SmartlockPro Self-Test GFCI tests itself even if you forget. Designed to meet the latest UL standard for auto-monitoring (self-test) our complete line of self-test GFCIs periodically conduct an automatic internal test to confirm that it can respond to a ground fault. With the slimmest profile on the market, the device allows for fast and easy installation, while Levitons patented reset lockout mechanism prevents reset of the GFCI if it is not wired or operating correctly. The SmartlockPro Self-Test GFCI is the smart choice in ground fault circuit interrupter protection.
Color Variations
  • Brown
NEMA
  • 5-20R
