Burndy VA30 Cast Cu Alloy VARILUG Terminal, Bolted, 1/0 Str - 300 Kcmil, 1 Pad Hole, 044" Hole Dia

Manufacturer: Hubbell-Burndy | Catalog # VA30 | Codale Part # 4519747
$367.80/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
Cast Cu Alloy VARILUG Terminal, Bolted, 1/0 Str - 300 Kcmil, 1 Pad Hole, 0.44" Hole Dia.

Technical Information

Conductor Size
2/0 AWG
Conductor Type
CU C Str-Size
Connection Type
Terminal
Material
Copper
Number of Holes
1 Hole
Plated?
No
Plating Type
Unplated
Stud Size
3/8 in

Manufacturer Information

Brand
Hubbell Incorporated
Sub Brand
Burndy

General Product Info

12-Digit UPC
781810005484
Product UPC
78181000548

Dimensions

Diameter
1-5/8 Inch
Height
1.22 Inch
Hole Size
0.44 in
Length
3.22 Inch
Overall Length
82 mm
Pad Width
1.13 in
Thickness
5/16 in
Width
1.91 in

Certifications and Compliance

Country of Origin
USA
CSA
No
Features
  • Type VA Copper V Type Terminal is a high copper alloy terminal for joining a wide range of cable to equipment pads or bar
  • Particularly suitable for use on extra flexible cable
  • One-wrench installation
