Product image for Panduit LAA350-12-15 Pan-Lug™ Aluminum 1 Hole Compression Lug
Image thumbnail 0
Image thumbnail 1
Image thumbnail 2
Email

Panduit LAA350-12-15 Pan-Lug™ Aluminum 1 Hole Compression Lug

Manufacturer: Panduit | Catalog # LAA350-12-15 | Codale Part # 4531004
$7,730.65/c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Prop 65 Warning Prop 65 Warning Buy American Compliant Buy American Compliant Installation / Instruction Manual
The LAA350-12-15 Aluminum Compression Connector Lug, one hole, is manufactured from high conductivity thick wall aluminum with an enclosed barrel for harsh environments. The color-coded barrels are marked with Panduit and specified competitor die index numbers for proper crimp die selection. Factory pre-filled with joint compound and tin-plated to inhibit corrosion. cULus listed up to 35kV and temperature rated to 90°C.

Technical Information

Barrel Length
2.25 in
Barrel Type
Standard
Cable Size
AWG
Material
Aluminum
Standard
CSA,E2186,UL
Stud Size
0.53 in
Tongue Thickness
0.38 in
Tongue Type
Standard
Tongue Width
1.51 in
Type
Aluminum single gang round receptacle cover

Manufacturer Information

Brand
Panduit Corp.
Sub Brand
Pan-Lug™

General Product Info

12-Digit UPC
613056857872
Color
Brown
Product UPC
61305685787

Dimensions

Overall Length
4.28 in

Certifications and Compliance

Buy American Compliant
Y
Country of Origin
India

Certifications & Compliance

Prop 65 Warning
N
Standards and Certifications
  • Standards Met: CSA Certified, UL Listed 486A-486B File #E52164
Prop 65
  • N
