Siemens 52PL4E2P 30 mm 120 VAC/VDC Green/Amber Lens Incandescent Pilot Light

Manufacturer: Siemens | Catalog # 52PL4E2P | Codale Part # 4536221
$505.62 /ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
30mm command/52, chrome finish heavy duty,watertight/oiltight point-of-purchase kit illuminated indicator light full voltage type, 120V AC/DC incandescent lamp, ba9s plastic lens 1 ea.: red, green,amber 1 52nl04 (stop) and 1 52nl11 (on) legend plate

Technical Information

Applications
Use in a panel to indicate the status of the motor, or other devices in the control circuit. Open type devices are designed for mounting in sheet metal enclosures or for mounting on flush plates.
Lumens
3
Operating Temperature
-35 to +70degrees C (-31 to +158degrees F)
Size
30 mm Pilot Device
Start Type
Single Input
Style
Metal Operator with Chorome Plating
Type
Non-Illuminated
Voltage
120 Volt

Manufacturer Information

Brand
Siemens
Sub Brand
Command/52

General Product Info

12-Digit UPC
662643527209
Color
Red
Product UPC
66264352720
Weight
0.650 lb

Dimensions

Height
2.8 Inch
Length
6.95 Inch
Width
5.500 in

Certifications and Compliance

Country of Origin
Mexico
