Intermatic PX100S 120 VAC 1 Amp Primary 13 VAC Secondary 100 W Safety Transformer with Stainless Steel Enclosure

Manufacturer: Intermatic | Catalog # PX100S | Codale Part # 4538707
$236.22/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Prop 65 Warning Prop 65 Warning Primary Spec Sheet
These safety transformers are specifically designed to supply 12,13 and 14 VAC and are suitable for direct connection to underwater pool/spa lights. A grounded shield between the primary and secondary winding assures safe operation. Built-in circuit protection will disconnect power to the transformer in case of an overload.

Technical Information

Applications
Pool or Garden Lighting, Spa Lighting, Fountain Lighting
Current
1 AMP
Enclosure
Type 3R Stainless Steel
Frequency
60 Hz
Input Voltage
120 V
Mounting Type
Bracket Mount
Output Voltage
12 V
Power Consumption
100 W
Size
7-1/4 HEIGHT X 5-1/4 WIDTH X 4-1/2 DEPTH IN, 18.4 HEIGHT X 13.3 WIDTH X 11.4 DEPTH CM
Standard
CCSAus Certified
Type
Safety Transformer
Wattage
100 Watt

Manufacturer Information

Brand
NA

General Product Info

12-Digit UPC
078275067561
Color
Gray
Product UPC
07827506756

Dimensions

Depth
4-1/2 Inch
Height
7-1/4 Inch
Warranty Length
1 yr
Width
5.25 in

Certifications and Compliance

Country of Origin
USA

Certifications & Compliance

Prop 65 Warning
Please see the Warning @ www.P65Warnings.ca.gov - DEHP
Features
  • Mounting brackets on the top and bottom
  • Built-in circuit protection disconnects power temporarily in case of overload
  • Complies with NEC Code 680.23 requirements for underwater luminaries
  • NA
