QTXE110150DC QTDC Series Bathroom Exhaust Fan with selectable 150, 130 or 110 CFM ENERGY STAR certified

Manufacturer: Broan-NuTone | Catalog # QTXE110150DC | Codale Part # 4540409
$325.51/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
The Broan® QT DC line of fans offers powerful airflow, with exceptional performance, and ultra-quiet sound. The DC motor is selectable between 110, 130, and 150 CFM. The QT DC also offers ultra-quiet sound ratings, producing only 0.4 sones at 150 CFM. This line of fans is the perfect combination of performance, efficacy, and silent operation.

Technical Information

Amperage
0.5 Amp
Duct Shape
Round
Motor Type
Energy Efficient Brushless Motor
Mounting Type
Ceiling
Nightlight
No
Power Rating
13.9 W
Type
Selectable
Voltage
120 Volt

Manufacturer Information

Brand
Broan-NuTone

General Product Info

12-Digit UPC
026715256808
Color
White
Grille Material
Polymeric
Housing Material
Steel
Product UPC
02671525680
Weight
11.16 lb

Dimensions

Grille Length
13-3/4 in
Grille Width
13 in
Height
7-5/8 Inch
Housing Height
7-5/8 in
Housing Length
10-1/2 in
Housing Width
11-3/8 in
Length
10-1/2 Inch
Warranty Length
3 yr
Width
13.75 in

Certifications and Compliance

Country of Origin
China
Features
  • Selectable CFM with speeds of 110-130-150
  • Quiet operation of <0.3-0.4-0.7 sones
  • DC motor helps maintain static pressure to ensure installed performance
  • Motor engineered for continuous operation
  • ENERGY STAR® Certified
  • Hanger bars to position housing anywhere on center joists
  • Unique patented spacers for mounting to engineered \"I\" joists
  • Rugged, galvanized steel construction to withstand moisture
  • UL listed for use over tub or shower with a GFCI branch circuit
  • Easy to install and/or replace existing product for DIY'ers
  • Quiet operation for a relaxing experience
Includes
  • Unique spacer for mounting to engineered \"i\" joists
  • Hanger bars
