Broan ZB110 30 CFM to 110 CFM Energy Star Qualified Fan

Manufacturer: Broan-NuTone | Catalog # ZB110 | Codale Part # 4541924
$292.22/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
The Broan® ZB110 ULTRA GREEN™ Multi-Speed Ceiling Bath Fan gives a premium performance for today's demanding home ventilation requirements. 110 CFM quickly reduce humidity and manage moisture in bathrooms up to 105 sq. ft. ULTRASilent™ technology operates at the lowest sound rating achievable, less than 0.3 sones. The ULTRASmart DC motor and control technology provides energy efficiency almost 10 times greater than ENERGY STAR® requirements. With ULTRAQuick™ installation technology the ZB110 provides the fastest, easiest, and most universal installation in remodel, retrofit, and new construction. The Broan® ZB110 has been specifically designed to meet both spot and continuous ventilation needs for various building codes and green building standards.

Technical Information

Airflow Rate
110 CFM
Amperage
0.3 Amp
Applications
For Bathrooms
Duct Shape
Round
Duct Size
6 in
Motor Type
DC Motor
Mounting Type
Ceiling
Nightlight
No
Power Rating
7.7 W
RPM
940 rpm
Standard
Energy Star Certified,HVI 2100 Certified,UL Listed For Use Over Bathtubs And Showers When Connected To A GFCI Protected Branch Circuit (Ceiling Mount Only)
Type
Multi-Speed, Horizontal Discharge
Voltage
120 Volt
Wattage
7.7 Watt

Manufacturer Information

Brand
Broan-NuTone
Sub Brand
UltraGreen

General Product Info

12-Digit UPC
026715201075
Color
White
Grille Material
Polymer
Housing Material
Galvanized Steel
Product UPC
02671520107
Weight
10.71 lb

Dimensions

Grille Length
13 in
Grille Width
13-3/4 in
Height
7-5/8 Inch
Housing Height
7-5/8 in
Housing Length
11-3/8 in
Housing Width
10-1/2 in
Length
10-1/2 Inch
Warranty Length
3 yr
Width
13.75 in

Certifications and Compliance

Country of Origin
China
Features
  • 110 CFM, Effective ventilation to remove moisture and reduce the risk of mold or mildew in most full baths
  • <0.3 Sones for Ultra quiet performance, you might not notice it's on
  • ULTRAQuick™ Installation Technology uses an exclusive telescoping mounting frame with pre-installed screws
  • Snap-in housing, snap-in blower, and an inside-out mounting duct connector for the fastest, easiest, most universal installation
  • Mounting Frame fits any type of joist, I-Joist or truss construction for a \"no guesswork\" installation to make the work fast and easy
  • ENERGY STAR® Certified to meet or exceed federal guidelines for energy efficiency for year-round energy and money savings
  • UL listed for use over bathtubs and showers when connected to a GFCI protected branch circuit (ceiling mount only) and for use in insulated ceilings (type IC)
  • Title 24 compliant
  • Powerful enough for rooms up to 100 sq. ft.
  • Brighter white grilles blend in to match most common ceiling paint
  • Corrosion resistant galvanized steel housing stands up to moisture
  • Brushless DC electronically controlled digital motor is 3Xmore efficient than standard AC powered ventilation
  • Very quiet, energy efficient , multi-speed exhaust fan
  • Powerful enough for rooms (including bathroom) up to 105 sq. ft.
  • Easy to install and/or replace existing product for DIY'ers
