Caddy EZR0200 Caddy EZ Riser, 2" Pipe

Manufacturer: Caddy Fasteners | Catalog # EZR0200 | Codale Part # 4544658
$1,984.89/c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
nVent CADDY EZ Riser, 2" Pipe

Technical Information

Material
Steel

Manufacturer Information

Brand
nVent Caddy

General Product Info

12-Digit UPC
782856956044
Finish
Electro Galvanized
Product UPC
78285695604
Weight
0.34 kg
Features
  • One-piece hinge design comes out of the box ready to install
  • Lack of loose hardware eliminates dropped or lost components, eliminating potential rework and speeding up installation
  • Carriage bolts seat into clamp, eliminating the need for multiples tools when tightening
  • Installs up to 60% faster than standard riser clamps and 45% faster than the industry-leading first generation EZ Riser
  • Multi-functional clamp can be installed in several approved orientations, simplifying material handling
  • Integrated second set of bolt holes allow the assembly to easily adapt from a riser clamp into a stand-off support
  • In spaces where full-sized riser clamps do not fit, integrated score marks allow for easy removal of ears
  • Retains listing when the ears are removed for close quarters, uniquely making the nVent CADDY EZ Riser capable of a listing in both installations
  • Recommended for suspending vertical steel pipe risers
  • No need to stock and use separate part families for standard and close quarter clamps to offer a full range of listed parts, reducing inventory by 38%
  • Conforms with Federal Specification WW-H-171 (Type 8), Manufacturers Standardization Society (MSS) SP-58 (Type 8)
Certifications
  • cUL ULC/ORD-C203
  • UL ANSI/UL 203
