NVENT HOF CED25 Double protection g

Manufacturer: nVent Hoffman | Catalog # CED25 | Codale Part # 4651319
$233.49/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
The rubber cable gland is easy to mount, cables and pipes can be pulled through easily without tools. This Double Protection Cables Entry For Wall Mounted Enclosures, CED, CED25 item measures 30.5x30.5x21.3mm has a material of EPDM color Light Gray, finish Smooth.

Technical Information

Color Coding
RAL 7035
Material
Rubber
Style
Metric: M25

Manufacturer Information

Brand
nVent Hoffman

General Product Info

12-Digit UPC
783510457518
Color
Gray
Finish
Smooth
Product UPC
78351045751
Weight
0.00 lb

Dimensions

Depth
0.84 Inch
Hole Diameter
25 mm
Width
0.00 in
Features
  • Description: The rubber grommet is very simple to use. The installation does not require tools, which in turn means lower work cost. The pushout membrane is a permanent seal until it is penetrated by a cable or pipe. Suitable for holes in materials of 0.5 to 4 mm thickness.
  • Material: EPDM, halogen free.
  • Temperature resistance: -40 C to +110 C.
  • Finish: RAL 7035.
  • Protection: IP 67.
  • The protection degree is maintained if the outside layer fails due to damage or external circumstances
  • The double layer sock is the optimal solution if the outside layer is exposed to external circumstances such as high pressure water
  • A potential disadvantage of the double layer however is that cables only pass through straight
  • A single layer sock is available (CES) to allow cable passing through with an angle but the protection degree might be at risk if this single layer fails
