Hubbell HBL20418H/LOCK INLET, 30A 600V, 3P4W

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBL20418 | Codale Part # 4693000
$765.56/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
Locking Devices, Hubbellock®, Industrial, Flanged Inlet, 30A 600V AC, 20A 250V DC, 3-Pole 4-Wire Grounding, Black phenolic interior, Aluminum housing, Non-NEMA, Screw Terminal, FS/FD Box Mounting, Metallic

Technical Information

Amperage
30 Amp
Applications
Extra Heavy Duty Industrial
Conductor Size
12-8 AWG
Current
20 Amp
Dielectric Strength
Withstands 2,000V minimum
Grounding
Grounding
Material
Composite
Mounting Type
Screw
Number of Poles
3 Pole
Number of Wires
4 Wire
Operating Temperature
-40 degrees C
Size
Standard Sized
Standard
CSA Standard,UL Standard
Tc Connection
Pressure Screw Terminals
Type
Single, Locking, Industrial Grade, Multi-Phase
Voltage
250 Volt
Wattage
18000 Watt
Wire Count
4
Wire Size
10-6 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Hubbell-Lock®

General Product Info

12-Digit UPC
783585017457
Color
Metallic
Environmental Conditions
Indoor Dry Unless Protected by Additional Means
Product UPC
78358501745
Weight
0.85 lb

Dimensions

Height
2.4 Inch
Length
4.56 Inch
Width
2.84 in

Certifications and Compliance

Country of Origin
USA
Features
  • Molded-in male contacts are resistant to damage and provide a consistently positive connection
  • Insulated non-metallic housing enhances safety and abuse resistance
  • Box terminals in conjunction with screws with pressure pads provide maximum termination strength and dependability
  • Metallic weather protective spring loaded cover provides protection from moisture and dust
  • FS/FD Mounting
