Greenlee 774 19-1/8" 750 MCM Copper Ratchet Cable Cutter

Manufacturer: Greenlee | Catalog # 774 | Codale Part # 515057
$1,689.08/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
Cutter assembly features two-speed mechanism saves cutting time by closing the blades rapidly and shifting to normal speed to perform the cut. No more pushing on stubborn release buttons-the blades open automatically when the cutis complete. Completely new ratchet mechanism improves durability. Narrow profile permits use in deep boxes, against walls or on floors. Durable, lightweight fiberglass handles. Cutting capacity of aluminium: 795.000KCMIL (MCM) (400.000sq-mm) maximum use, 750KCMIL (MCM) (400.000sq-mm) frequent use. Cutting capacity of communication cables: 1-3/16 inch diameter maximum use. Cutting capacity of copper : 750 KCMIL (MCM) (400.000sq-mm) maximum use, 500 KCMIL (MCM) (240.000sq-mm) frequent use.

Technical Information

Applications
For Two-Speed Mechanism Saves Cutting Time by Closing the Blades Rapidly and Shifting to Normal Speed to Perform the Cut. Narrow Profile Permits Use in Deep Boxes, Against Walls or on Floors
Handle Type
Light Weight
Type
High Performance Ratchet

Manufacturer Information

Brand
Greenlee

General Product Info

12-Digit UPC
783310018780
Handle Material
Fiberglass
Product UPC
78331001878
Weight
5.800 lb

Dimensions

Overall Length
19-1/8 in

Certifications and Compliance

Country of Origin
USA
Features
  • Two-speed mechanism saves linemen cutting time by closing the blades rapidly and shifting to normal speed to perform the cut
  • No more pushing on stubborn release buttons - the blades open automatically when the cutis complete
  • Completely new ratchet mechanism improves durability
  • Cable cutter's narrow profile permits use in deep boxes, against walls or on floors
  • Durable, lightweight fiberglass handles
  • U.S. Patent #6,766,581
Application
  • Two-speed mechanism saves cutting time by closing the blades rapidly and shifting to normal speed to perform the cut. Narrow profile permits use in deep boxes, against walls or on floors.
