Raco 271 Concrete Ring, Welded, 2-1/2" Deep, Single Row 1/2" & 3/4" KO's

Manufacturer: Raco | Catalog # 271 | Codale Part # 897
$5,217.26/c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Prop 65 Warning Prop 65 Warning Primary Spec Sheet MDM Safety Data Sheet
Concrete Ring, Welded, 2-1/2 in. Deep, Single Row 1/2 & 3/4 in. KO's

Technical Information

Applications
Electrical
Cable Entry
Knockouts for conduit
Material
Steel
Size
2-1/2 IN
Type
Concrete ring

Manufacturer Information

Brand
RACO

General Product Info

12-Digit UPC
050169002711
Color
Gray
Construction
Welded
Product UPC
05016900271
Weight
0.654 lb

Dimensions

Depth
2-1/2 Inch
Height
4 Inch
Length
2.779 Inch
Width
4 in

Certifications and Compliance

Country of Origin
Mexico

Certifications & Compliance

Prop 65 Warning
No
Features
  • Single row of 1/2 in. and 3/4 in. knockouts
  • Flat sides provide excellent contact for locknuts
  • External ears are used to nail the concrete ring to the wood form
  • Top cover is removable for before-pour work
  • Waxed fixture ears prevent concrete from interfering with the threads
  • Ears on inside of concrete ring are for fixtures
  • Can support a light fixture up to 50 pounds
  • 30.8 cu. in. capacity
Prop 65
  • No
